PLATIN (MB 528RD)
System input power (W) : 24 - 6 - 12
Cut Size(mm) : 100 - 80 - 145
 6W |  12W |  24W | |
|---|---|---|---|
| System input power (W) | 6 | 12 | 24 |
| Input voltage range (V-AC/Hz) | 220-240/50-60 | 220-240/50-60 | 220-240/50-60 |
| Power factor | 0.63 | 0.74 | 0.85 |
| Nominal luminous Flux (Lm) | 420 | 840 | 1680 |
| Color rendering index (Ra) | 45 | 45 | 45 |
| Light distribution angle (degrees) | 45 | 45 | 45 |
| Cut Size(mm) | 80 | 100 | 145 |
| Dimension(mm) | 110*50 | 130*65 | 173*105 |
| Ingress Protection (IP) | 20 | 20 | 20 |
| Humidity range (%) | 10~90RH | 10~90RH | 10~90RH |
| Ambient temperature range (°C) | -20 ~ +45 | -20 ~ +45 | -20 ~ +45 |
| Product Code | MB006-528 RD | MB012-528 RD | MB024-528 RD |
| Color Temperature | Warm-Cool-Natural | Warm-Cool-Natural | Warm-Cool-Natural |
| LED Module Life Time | 5000(h) | 5000(h) | 5000(h) |
| Lumen Maintenance | L70B10 | L70B10 | L70B10 |
MB006 528RD
6w , 420 lm , beam angle 45 , cut size 80 , Size 110.50
MB012 528RD
12w , 840 lm , Beam angle 45 , Cut size 100 , Size 130.65
MB024 528RD
24w , 1680 lm , beam angle 45 , Cut size 145 , Size 173.105
Test Report 6w , 12w , 24wDownload Now
SpecificationDownload Now
