AFRA (20071024-50)
System input power (W) : 24 - 50
Light Source : -
Cut Size(mm) : 290*590 - 600*600
| 24W | 50W | |
|---|---|---|
| System input power (W) | 24 | 50 |
| Input voltage range (V-AC/Hz) | 220~240/50~60 | 220~240/50~60 |
| Power factor | 0.84 | 0.97 |
| LED module type | - | - |
| LED module structure | - | - |
| Light Source | - | - |
| Nominal luminous Flux (Lm) | 2160 | 4500 |
| Nominal system luminous efficiency (Lm/W) | - | - |
| Number of LEDs (pcs) | - | - |
| Nominal color temperature (°K) | - | - |
| Color rendering index (Ra) | 80 | 80 |
| Lumen maintenance factor at 1000 hours | 98% | 98% |
| Lumen maintenance group at 6000 hours | A | A |
| Cut Size(mm) | 290*590 | 600*600 |
| Dimension(mm) | 300*600*80 | 620*620*80 |
| Light distribution angle (degrees) | 120 | 120 |
| Material (PC) | - | - |
| Ingress Protection (IP) | 42 | 42 |
| Weight (Kg) | - | - |
| Rated life in ambient temperature 25 °C | 5000(hrs) | 5000(hrs) |
| Rated life in ambient temperature 45 °C | 5000(hrs) | 5000(hrs) |
| Maximum junction temperature LED (°C) | - | - |
| Humidity range (%) | 10~90RH | 10~90RH |
| Ambient temperature range (°C) | -20~ +50 | -20~ +50 |
| Product Code | 20071050 | 20071024 |
