| System input power (W) | 3w | 6w |
| Nominal luminous Flux (Lm) | 210 | 420 |
| Dimension(mm) | 150*80*60 | 310*80*60 |
| LED Chip Brand | Bridgeluxe / Epistar | Bridgeluxe / Epistar |
| Ingress Protection (IP) | 20 | 20 |
| LED module type | SMD | SMD |
| Ambient temperature range (°C) | -20~ +50 | -20~ +50 |
| Light distribution angle (degrees) | 120 | 120 |
| Input voltage range (V-AC/Hz) | AC200_250V/50_60Hz | AC200_250V/50_60Hz |
| Power factor | 0.68 | 0.68 |
| LED Module Life Time | 30000 | 30000 |
| Body | White/Black | White/Black |
| Color rendering index (Ra) | 80 | 80 |
| Color Temperature | Natural | Natural |
| Lumen maintenance group at 6000 hours | A | A |
| Lumen Maintenance | L70B10 | L70B10 |
| Material (PC) | Aluminum | Aluminum |
| Product Code | MB003/K747W | MB006/K4748W |
MB003 K747w
3w , 210 lm , White Body , beam angle 120 , size 150.80.60 , SMD
MB006 K748w
6w , 420 lm , White Body , beam angle 120 , Size 310.80.60 , SMD
