AMITIS 10053004

Interior Embedded Halogen LED Light

System input power (W) : 4w

Light Source : COB LED

View Full Specifications
AMITIS 10053004
System input power (W) 4w
Input voltage range (V-AC/Hz) 85~265/50~60
Power factor 0.63
LED module type With separate ballast
LED module structure Integrated
Product Code
Light Source COB LED
Nominal luminous Flux (Lm) 480
Nominal system luminous efficiency (Lm/W)
Number of LEDs (pcs) 1
Nominal color temperature (°K) 2800-6200
Color rendering index (Ra) 80
Lumen maintenance factor at 1000 hours 98%
Lumen maintenance group at 6000 hours A
Light distribution angle (degrees) 24
Dimension(mm) 200x160x60
Material (PC) Aluminum
Ingress Protection (IP) 65
Weight (Kg)
Rated life in ambient temperature 25 °C 50000 (hrs)
Rated life in ambient temperature 45 °C 35000 (hrs)
Maximum junction temperature LED (°C) 120
Humidity range (%) 10~90RH
Ambient temperature range (°C) -20 ~ +45
Product Code

2x2W , Two side , 480 lm ,  Size 200x160x60 , IP54

Specification CatalogueDownload Now
Installation GuideDownload Now
